FANUC PLUS CONTROL INCLUDES:
Part Program Storage & Edit 4 MB
No. of registerable programs Total 1,000 pairs
Custom Macro B (82 Common Variables)
Additional 600 Common Variables for Custom Macro B
Cycles for Turning (G70 - G76)
Multiple Repetitive Canned Cycles Type I & II for Drilling (G80 - G89)
Polar Coordinate Interpolation
Rigid Tapping
Variable Lead Thread Cutting
Thread Cutting Cycle Retract
Tool Offset Measurement Value Direct Input B
Programmable Tool Geometry and Wear Offset Input (G10)
Inch/Metric Conversion
Chamfer and Corner Radius by G-code
Displaying Operation Time and Number of Parts
Patternize
Spindle speed , surface speed S-code (4-digit)
Work Coordinate Setting (G-54-G59)
Increment System 1/10
Ethernet Function/100 Base
Tool Offset measurement Value Direct Input B
Background Edit
Graphic Display (manual guide i)
WORK CLAMP CONFIRMATION-ONE SIDE
Verifies that the drawbar stroke for clamp to unclamp has occurred.
CHIP CONVEYOR, HINGE TYPE, REAR DISCHARGE
SMALL WORK FEEDER TABLE ASSEMBLY WF10L-160
INCLUDES LIGHT CURTAIN AND GUARDING AND FRONT DOOR WITH INTERLOCK
10 stations
Max stacking height of 450mm / 17.7in.
Part OD range of 30 - 160mm / 1.18 in. - 6.29 in.
Max weight per pallet 35 Kg / 77 lb.
Includes interface cables
Pallets quoted separately
(10) STANDARD PALLET (3 POLE ADJUSTABLE) 160II
PART OD RANGE OF 30 - 160MM
(4) RH TURN TOOL HEAD (25MM SHANK)
(4) PLAIN TOOL HEAD (40MM SHANK)
